H-BEAM END FACE MILLING MACHINES is a high performance multipurpose machining unit which is used for the cutting and finishing of various types of engineering grade metallic and alloyed components to make unique designs and cuts with higher precision and accuracy. It is provided with high performance electrical motor which is responsible for the smooth and controlled functioning of the mechanical components fixed within the mechanism. End Miller and Face Miller Machine is also provided with a small control panel with the help of which operator can easily feed the input.

Features

  • All castings Components are of G-20 grade with 180 x 10 H.B hardness and are well designed and heavily ribbed for the best rigidity and dampening capacity.
  • All working parts properly seasoned and machine finished on imported machines, followed by proper scraping, to obtain more precision working and long life.
  • Vertical slide ways and the grinding wheels, creating a perpendicular movement of the spindle in relation to the working table, the housing construction is also designed for better rigidity.
  • Precision scraped Flat Rectangular box type guideways for Column and Vertical head.
  • Gear Box placed in such a position as to enhance the appearance of the whole machine.
  • All Gears are EN-36 material and properly heat treated.
  • Safety limit switches are provided for the vertical movement of the Milling head and Horizontal movement of the column.
  • The lubrication system supplies oil to guide ways and lead screws as the machine operates. This ensures all the critical components are lubricated with the right amount of oil at all times.
  •  Rapid movement of Column and Vertical head by electric motor for faster setting.

Model No. Units PEM 080 PEM 125 PEM 150 PEM 200 PEM 315 PEM 350 PEM 450
No. of Speeds Nos. 4 4 4 4 4 4 4
Speed Range RPM 120 - 500 120- 500 120 - 500 100 -5 400 75 - 300 75 - 300 25 - 100
Main Motor HP 3 5 7.5 10 15 20 30
Spindle Dia MM 90 120 120 120 140 140 180
Horizontal Traverse MM 80 100 110 125 140 150 150
Main Spindle Socket ISO 40 50 50 50 50 50 50
Cutter Capacity on Mild Steel MM 80 125 150 200 315 350 450
Max. Height of the Spindle Axis MM 1000 1100 1200 1300 1500 1800 2000
Longitudinal Traverse MM 2000 2200 2500 3000 3500 4000 5000
Longitudinal Traverse Movement Nos. 6 Speed (Including One Rapid)
Vertical Traverse Movement Nos. 4 Speed (Including One Rapid)
